Topic 6: Misc. Questions

You have an Azure App Service plan named ASP1.
CPU usage for ASP1 is shown in the following exhibit.

You have an Azure subscription that contains two Log Analytics workspaces named Workspace 1 and Workspace? and 100 virtual machines that run Windows Server.
You need to collect performance data and events from the virtual machines. The solution must meet the following requirements:

• Logs must be sent to Workspace! and Workspace?
• All Windows events must be captured
• All security events must be captured.

What should you install and configure on each virtual machine?

A. the Azure Monitor agent

B. the Windows Azure diagnostics extension (WAD)

C. the Windows VM agent

A.   the Azure Monitor agent

Explanation:
https://learn.microsoft.com/en-us/azure/azure-monitor/agents/agents-overview Azure Monitor Agent (AMA) collects monitoring data from the guest operating system of Azure and hybrid virtual machines and delivers it to Azure Monitor for use by features, insights, and other services, such as Microsoft Sentinel and Microsoft Defender for Cloud. Azure Monitor Agent replaces all of Azure Monitor's legacy monitoring agents.

You have an Azure App Service app named App1 that contains two running instances.
You have an autoscale rule configured as shown in the following exhibit.
For the Instance limits scale condition setting, you set Maximum to 5.
During a 30-minute period, App1 uses 80 percent of the available memory.
What is the maximum number of instances for App1 during the 30-minute period?

A. 2

B. 3

C. 4

D. 5

A.   2

You deploy an Azure Kubernetes Service (AKS) cluster named Cluster1 that uses the IP addresses shown in the following table.

You need to provide internet users with access to the applications that run in Cluster1.
Which IP address should you include in the DNS record for Ousted?

A. 172.17.7.1

B. 131.107.2.1

C. 192.168.10.2

D. 10.0.10.11

B.   131.107.2.1

Explanation:
When any internet user will try to access the cluster which is behind a load balancer, traffic will first hit to load balancer front end IP. So in the DNS configuration you have to provide the IP address of the load balancer.

You have an Azure web app named webapp1.

You have a virtual network named VNET1 and an Azure virtual machine named VM1 that hosts a MySQL database. VM1 connects to VNET1.
You need to ensure that webapp1 can access the data hosted on VM1.
What should you do?

A. Connect webapp1 to VNET1.

B. Deploy an internal load balancer

C. Deploy an Azure Application Gateway,

D. Peer VNET1 to another virtual network

C.   Deploy an Azure Application Gateway,

You have an Azure Storage account named storage1.
You have an Azure App Service app named app1 and an app named App2 that runs in an Azure container instance. Each app uses a managed identity.
You need to ensure that App1 and App2 can read blobs from storage1 for the next 30 days.
What should you configure in storage1 for each app?

You have an Azure subscription named Subscription1 that contains a virtual network named VNet1. VNet1 is in a resource group named RG1.
Subscription1 has a user named User1. User1 has the following roles;
• Reader
• Security Admin
• Security Reader
You need to ensure that User1 can assign the Reader role for VNet1 to other users. What should you do?

A. Assign User1 the Contributor role for VNet1.

B. Remove User from the Security Reader and Reader roles tot Subscription1.

C. Assign User1 the Network Contributor role for VNet1.

D. Assign User1 the User Access Administrator role for VNet1

D.   Assign User1 the User Access Administrator role for VNet1

You have an Azure subscription.

Users access the resources in the subscription from either home or from customer sites.
From home, users must establish a point-to-site VPN to access the Azure resources. The users on the customer sites access the Azure resources by using site-to-site VPNs.
You have a line-of-business app named App1 that runs on several Azure virtual machine.
The virtual machines run Windows Server 2016.
You need to ensure that the connections to App1 are spread across all the virtual machines.
What are two possible Azure services that you can use? Each correct answer presents a complete solution.
NOTE: Each correct selection is worth one point.

A. a public load balancer

B. Traffic Manager

C. an Azure Content Delivery Network (CDN)

D. an internal load balancer

E. an Azure Application Gateway

D.   an internal load balancer
E.   an Azure Application Gateway

Explanation:
Line of Business WebAPP works on VMs need internal load balancer. So D is needed.
Then deploy WebAPP on VMs, check the link. https://docs.microsoft.com/enus/azure/application-gateway/quick-create-portal So B is needed as well. The original answer is not accomplished.

You have an Azure subscription.
You plan to migrate 50 virtual machines from VMware vSphere to the subscription.
You create a Recovery Services vault.
What should you do next?

A. Configure an extended network

B. Create a recovery plan.

C. Deploy an Open Virtualization Application (OVA) template to vSphere

D. Configure a virtual network

C.   Deploy an Open Virtualization Application (OVA) template to vSphere

Explanation: To migrate virtual machines from VMware vSphere to Azure, you need to use Azure Migrate, which is a service that helps you assess and migrate your on-premises workloads to Azure. Azure Migrate uses an appliance that you deploy as an Open Virtualization Application (OVA) template to vSphere. The appliance discovers the virtual machines and sends metadata and performance data to Azure Migrate. You can then use Azure Migrate to assess the readiness, cost, and sizing of the virtual machines for migration. You can also use Azure Migrate to replicate and migrate the virtual machines to Azure.
References:
  • About Azure Migrate
  • Prepare VMware servers for assessment and migration to Azure with Azure
  • Migrate Server Migration

You have an Azure Storage account named storage1 that contains a blob container. The blob container has a default access tier of Hot. Storage1 contains a container named container!
You create lifecycle management rules in storage1 as shown in the following table.
